Cudy BE3600 Wi-Fi 7 Ceiling AP Dual Band with PoE Adapter
A wall/ceiling-mounted WiFi 7 AP designed for malls, offices, campuses, and other high-density scenarios, featuring a 2.5G PoE IN port and a PoE Out port.
- Broadcom 2 GHz Quad-Core CPU
- 4-Stream Dual-Band Wi-Fi 7
- 2882 Mbps + 688 Mbps Wi-Fi
- 1× Shielded 2.5GbE PoE IN
- 1× Shielded GbE PoE Out
- 802.3at, Passive PoE, DC
- Watchdog, Schedule Reboot
- Covers 120 m² (1,300 ft²)
- 200 Connected Devices
(CU-AP3600_P)
Cudy BE3600 Wi-Fi 7 Ceiling AP Dual Band with PoE Adapter
Pack Includes:
1 * AP3600_P
1 * Power Adapter 48V 802.3at passive
1 * Mounting Kit
1 * Ethernet Cable
1 * Installation Guide
Cudy BE3600 Wi-Fi 7 Ceiling AP Dual Band with PoE Adapter- Specifications:
| Model Version | AP3600 1.0 | |
|---|---|---|
| CPU | CPU Details | 2.0 GHz Quad-Core, ARM Cortex-A7 |
| Memory/Storage | Flash/ROM | 128 MB (1 Gbit) NAND |
| DDR/RAM | 512 MB (4 Gbit) DDR3L | |
| Wireless | 5 GHz Wi-Fi Speed | 2882 Mbps |
| 2.4 GHz Wi-Fi Speed | 688 Mbps | |
| 5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| Wi-Fi Antennas | 4× Internal | |
| FEM or PA/LNA |
|
|
| Beamforming | True | |
| Range Performance | Max: 220 m (722 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|
| Wall Performance | Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'') |
|
| Interfaces | 2.5G RJ45 Ports | 1 |
| Gigabit RJ45 Ports | 1 | |
| Ethernet Notes | Accepts PoE powering | |
| LED | System | |
| Physical Buttons | Reset Button | |
| Power Input |
|
|
| Power | Power Methods |
|
| DC Input | 12V 1A | |
| Passive PoE Input | 48 ~ 57V | |
| Power Adapter | AP3600 | DC Adapter in the box: Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC AP3600_P | PoE Adapter in the box: Input: 100 ~ 240 V, 50/60 Hz AC Output: 48V Passive PoE |
|
| Max Power Consumption (W) | 10W | |
| Reliability | Advanced | Hardware Watchdog |
| EMC | ESD: Contact: 4kV; Air: 8kV | |
| Environment |
|
|
| Certifications | FCC, CE | |
| Mechanical | Installation |
|
| Dimension | 231.9×231.9×57.1 mm 9.13×9.13×2.25 inches |
|
| Product Weight | 435.0 g (15.34 oz.) | |
| Package Content |
|
|
| Ordering Information | Retail Package Weight | EU: 903.8 g (31.88 oz.) |
| Retail Package Dimension | 310×238×73 mm 12.2×9.37×2.87 inches |
|
| Units per Carton | 10 | |
| Carton Net Weight | EU: 9.1 kg (20.06 lbs) | |
| Carton Gross Weight | EU: 10.0 kg (22.05 lbs) | |
| Carton Dimension | 49.5×38.7×33.2 cm 19.49×15.24×13.07 inches |
|
- Actual wireless data throughput will vary as a result of network conditions, client limitations, and environmental factors including building layout, obstacles, and client location.
- The PoE-Out port only provides power when the PoE-In port is plugged in 802.3at power source.
- The wireless coverage claim serves as a reference only. Coverage performance will vary due to environmental factors including building layout, obstacles, traffic volume and density, and device location. For optimal coverage, please place the device in a central location within the area requiring Wi-Fi.
- Actual performance for multiple devices may be affected by the types of applications used, the total available bandwidth, and the capabilities of your devices. Connecting older Wi-Fi devices (legacy standards) may reduce overall efficiency. Using efficiency features requires compatible client devices that also support those features. Find more information about supported efficiency features in the software section of the Specs spreadsheet.
Shipping Specifications | |
| SKU | CU-AP3600_P |
| Model # | AP3600_P |
| Brand | CUDY |
| Shipping Weight | 0.9030kg |
| Shipping Height | 0.073m |
| Shipping Length | 0.238m |
| Unit Of Measure | ea |
