Managed Gigabit Switch with SFP



Available with 24 or 48 RJ45 Gigabit ports, the EdgeSwitch™ Lite delivers robust performance and intelligent switching for growing networks.

Powerful Enterprise Switch Models
The EdgeSwitch™ Lite simultaneously processes traffic on all ports at line rate without any packet loss. Total non-blocking throughput: up to 26 Gbps for the fanless, 24-port models and up to 70 Gbps for the 48-port models.

Enterprise-Class Features
The EdgeSwitch™ Lite supports an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Optic Fibre Backhaul
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.

Features

  • (48) Gigabit RJ45 Ports
  • (2) SFP+ Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 70 Gbps
  • Switching Capacity: 140 Gbps
  • Forwarding Rate: 104.16 Mpps
  • Maximum Power Consumption: 56W
  • Rack- or Wall-Mountable
  • DC Input Option (Redundant or Stand-Alone)



(ES-48-Lite)

EdgeMAX Switch 48 Port LITE

Package Includes

  • 1 x EdgeSwitch 48 LITE
  • 2 x Rack Mounting Brackets
  • 8 x Mounting-Bracket Screws (#10-32 x 5/8")
  • 4 x Mounting Screws (#10-32 x 5/8")
  • 4 x Cage Nuts (#10-32 x 5/8")
  • 1 x Power Cord
  • Quick Start Guide

EdgeMAX Switch 48 Port LITE - Specifications

EDGESWITCH
Dimensions 443 x 43 x 286 mm (17.44 x 1.69 x 11.26")
Weight 3.65 kg (8.05 lb) 3.56 kg (7.85 lb)
Total Non-Blocking Throughput 70 Gbps
Max. Power Consumption 56W
Power Method 100-240VAC/50-60 Hz, Universal Input DC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector
Power Supply AC/DC, Internal, 56W DC
Networking Interface (48) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1/10 Gbps SFP+ Ethernet Ports (2) 1 Gbps SFP Ethernet Ports
Management Interface (1) RJ45 Serial Port, Ethernet In/Out Band
Certifications CE, FCC, IC
Rackmount Yes, 1U High
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Noncondensing

Shipping Specifications

SKU ES-48-Lite
Model # ES-48-Lite
Barcode # 8.18E+11
Brand Ubiquiti
Shipping Weight 3.9000kg
Shipping Width 0.335m
Shipping Height 0.080m
Shipping Length 0.530m
Shipping Cubic 0.014204000m3
Unit Of Measure ea
