Ubiquiti U7 Pro Wall SKU: U7-Pro-Wall Tech Specs: Click Here Installation Guide: Click Here Description: Wall-mounted WiFi 7 AP with 6 spatial streams and 6 GHz support tailored for home builders with seamless installation options.

Features:

  • WiFi 7 with 6 GHz support
  • 6 spatial streams
  • 140 m² (1,500 ft²) coverage
  • 300+ connected devices
  • Powered using PoE+
  • 2.5 GbE uplink
  • Versatile deployment with optional Flush Mount and Table Stand accessories*

(U7-PRO-WALL)



Mechanical
Dimensions 150 x 103 x 36 mm (5.9 x 4.1 x 1.4")
Weight 580 g (1.3 lb)
Enclosure material Polycarbonate, aluminum
Mount material Aluminum
Hardware
Networking interface (1) 1/2.5 GbE RJ45 port
Management interface Ethernet
Power method PoE+
Power supply UniFi PoE switch
Supported voltage range 44—57V DC
Max. power consumption 22W
Max. TX power
2.4 GHz
5 GHz
6 GHz
22 dBm
26 dBm
23 dBm
MIMO
2.4 GHz
5 GHz
6 GHz
2 x 2
2 x 2
2 x 2
Throughput rate
2.4 GHz
5 GHz
6 GHz
688 Mbps
4324 Mbps
5764 Mbps
Antenna gain
2.4 GHz
5 GHz
6 GHz
4 dBi
5 dBi
6 dBi
LEDs White/blue
Button Factory reset
Mounting Wall (Included)
Table stand, flush mount (Optional)
Ambient operating temperature -30 to 60° C (-22 to 140° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g/n/ac/ax/be
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
SKU U7-PRO-WALL
Model # U7-Pro-Wall
Barcode # 8.10E+11
Brand Ubiquiti
Shipping Weight 0.7800kg
Shipping Width 0.156m
Shipping Height 0.076m
Shipping Length 0.800m
Shipping Cubic 0.009484800m3
Unit Of Measure ea
